Loadmac 825 Super Reach - 2 Way or 4 Way
More Reach. More Power. More Performance.
With a 2500kg lifting capacity, the Loadmac 825 boasts genuine one-side offload, multi-directional steering option and superior reach and stability when working in the toughest conditions.
- Tough, light & compact
- Genuine 2500kg Lift Capacity from the far side of the truck or trailer
- New Loadmac stock now available
- Nationwide technical support
Loadmac is the truck mounted forklift which is raising the bar:
- 2,500kg lift capacity @ 600mm load centre
- 3 or 3.5m mast
- Super reach - standard
- The most powerful machine in its class
- Designed to fit all standard mounting kits
Our 2 Way Model features Standard rear-wheel steering, allowing for movement in a forward and reverse direction.
Our 4 Way Model features multi-directional steering, meaning it can move forward, backward, and sideways, making it more versatile for manoeuvring in tight spaces and handling long loads.
Detailed Specs - 2 WAY MODEL
Standard Features
- All-Wheel Drive with Poclain Wheel Motors
- Differential Lock
- Hydraulic Front Stabiliser Legs
- Integrated Sideshift
- Class 3B, 1200mm Forks
- Hydrostatic Steering
- Triple-Coat Paint Process
- ‘Man-on-the-Ground’ Controls
- Sacrificial Rear Corner Protection Plates
- Fold-Down Operator Safety Arm / Arm Rest
- ROPS/FOPS Cabin
- Integrated Reach & Carriage Tilt System
- One Direction Slew Ring - Provides full 90° steering in both directions
- Dual Lighting
- Full LED Work Lights
- Grommet LED Road Lighting
- Flashing Amber Safety Beacon & Reverse Alarm
- Self-Draining Laminated Glass Roof (for rain protection)
- Operator Protection Mesh
- Ground Start Key Position
- Anti-Vibration Rubber Mounted Cabin
- Lightweight Plastic Fuel Tank with Electronic Level Gauge
- 500 Hours Chrome on Exposed Rams
- Mast Anti-Burst Valves
- Fold-Up Suspension Seat with Occupancy Sensor
- Hi-Visibility Coiled Operator Seatbelt with Interlock
- Electric Parking Brake
- IP67 Switches
- IP66 Multi-Function Instrument Panel
- Retractable Transport Chain Pins
- Transport Chain Kit (with adjustable end plate)
- Suzi Electric Cable
- Geomet Coated Mast Chains
- Easy Access Bonnet (for quick & easy access)
- Rear Tie Down Crosses and Front Tie Down Holes
Machine Specifications (2 Way)
- Manufacturer: Loadmac
- Model: 825 Super Reach - 2 Way
- Lifting Capacity: 2500kg
- Load Centre: 600mm
- Unladen Weight: 2780kg
- Fuel Type: Diesel
- Engine: Hatz 59 HP
- Transmission: Hydrostatic
- Traction: 3 x 3 All Wheel Drive
- Maximum Speed: 12.8 kph
- Gradeability: 35%
- Overall Width: 2420mm
- Overall Length: 2380mm
- Cabin Height: 2450mm
- Frame Opening: 1650mm
- Overhang: Minimum - 1346mm / Typical - 1400mm
- Ground Clearance: 270mm
- Mast Type: 2 Stage with ISR One Side offload system
- Mast Height 3.0m: Extended - 4900mm / Collapsed - 2500mm
- Mast Height 3.5m: Extended - 5370mm / Collapsed - 2740mm
- Carriage Type: 3A with Integrated Tilt and Side shift Functions
- Sideshift Range: 150mm
- Tilt Range: 12 degress fwd / 10 degrees back
- Forks: 1200mm x 100mm x 50mm Class 3
- Front Tyres: 10 x 16.5 - All Terrain
- Rear Tyres: 10 x 16.5 - All Terrain
New with the 825 (2 Way)
- 59HP Hatz Tier 4 Engine (NO DEF or DPF Filter)
- Improved Weatherproof Seat Switch & Loom Connection
- Improved Weatherproof Seat Switch & Loom Connection
- Mast Hydraulic Dump Valve Switch for Mounting
- Revised Rear Levers for Ground Mounting with Speed Control
- Front Light Guards
- Locking Bonnet Handle with Secondary Security Latch
- Interlocked Orange Seatbelt
- Separate, Removable Hydraulic Tank
- New iSR Cylinder Valving and PRV for iSR Protection
- 500 Hour Chrome Rods on Cylinders
Detailed Specs - 4 Way Model
Standard Features
- All-Wheel Drive with Poclain Wheel Motors
- Differential Lock
- Hydraulic Front Stabiliser Legs
- Integrated Sideshift
- Class 3B, 1200mm Forks
- Hydrostatic Steering
- Triple-Coat Paint Process
- ‘Man-on-the-Ground’ Controls
- Sacrificial Rear Corner Protection Plates
- Fold-Down Operator Safety Arm / Arm Rest
- ROPS/FOPS Cabin
- Integrated Reach & Carriage Tilt System
- One Direction Slew Ring - Provides full 90° steering in both directions
- Dual Lighting
- Full LED Work Lights
- Grommet LED Road Lighting
- Flashing Amber Safety Beacon & Reverse Alarm
- Self-Draining Laminated Glass Roof (for rain protection)
- Operator Protection Mesh
- Ground Start Key Position
- Anti-Vibration Rubber Mounted Cabin
- Lightweight Plastic Fuel Tank with Electronic Level Gauge
- 500 Hours Chrome on Exposed Rams
- Mast Anti-Burst Valves
- Fold-Up Suspension Seat with Occupancy Sensor
- Hi-Visibility Coiled Operator Seatbelt with Interlock
- Electric Parking Brake
- IP67 Switches
- IP66 Multi-Function Instrument Panel
- Retractable Transport Chain Pins
- Transport Chain Kit (with adjustable end plate)
- Suzi Electric Cable
- Geomet Coated Mast Chains
- Easy Access Bonnet (for quick & easy access)
- Rear Tie Down Crosses and Front Tie Down Holes
Machine Specifications (4 Way)
- Manufacturer: Loadmac
- Model: 825 Super Reach - 4 Way
- Lifting Capacity: 2500kg
- Load Centre: 600mm
- Unladen Weight: 2871kg (3.1 metre mast)
- Fuel Type: Diesel
- Engine: Hatz 59 HP
- Transmission: Hydrostatic
- Traction: 3 x 3 All Wheel Drive
- Maximum Speed: 12.8 kph
- Gradeability: 35%
- Overall Width: 2420mm
- Overall Length: 2380mm
- Cabin Height: 2450mm
- Frame Opening: 1650mm
- Overhang: Minimum 1346mm / Typical 1400mm
- Ground Clearance: 270mm
- Mast Type: 2 Stage with ISR One Side offload system
- Mast Height 3.5m: Extended 5370mm / Collapsed: 2740mm
- Carriage Type: 3A with Integrated Tilt and Sideshift Functions
- Sideshift Range: 150mm
- Tilt Range: 12 degress fwd / 10 degrees back
- Forks: 1200mm x 100mm x 50mm Class 3B
- Front Tyres: 10 x 16.5 - all terrain
- Rear Tyres: 10 x 16.5 - all terrain
New with the 825 (4 Way)
- 59HP Hatz Tier 4 Engine (NO DEF or DPF Filter)
- Multi Directional Mode Mast control system
- Redesigned Hydraulic Fan “Constant Run” Circuit
- Improved Weatherproof Seat Switch & Loom Connection
- Mast Hydraulic Dump Valve Switch for Mounting
- Revised Rear Levers for Ground Mounting with Speed Control
- Front Light Guards
- Locking Bonnet Handle with Secondary Security Latch
- Interlocked Orange Seatbelt
- Separate, Removable Hydraulic Tank
- New iSR Cylinder Valving and PRV for iSR Protection
- 500 Hour Chrome Rods on Cylinders
- Manual Fold-Down Load Rest (Option)
Loadmac 825: The Ultimate Truck-Mounted Forklift for Heavy-Duty Performance
Engineered for power, precision, and operator efficiency, the Loadmac 825 Super Reach is built to handle the toughest material handling challenges. With a 2,500kg lifting capacity and an industry-first Integrated Second Reach (iSR) system, it allows for true one-side unloading, even inside a curtainsider.
✅ 2-Way Model – Traditional forklift steering for straight-line efficiency in standard applications.
✅ 4-Way Model – Multi-directional steering with side shift capability, ideal for handling long and bulky loads in tight spaces.
Designed for a Range of Industries
✔ Scaffolding – Move long, heavy scaffolding safely and efficiently.
✔ Turf – Handle large pallets of grass and topsoil with precision.
✔ Brick & Block – Engineered for safe and stable handling of masonry products.
✔ Ceramic Tiles – Transport fragile and heavy tile pallets securely and without damage.
✔ Ag Feed & Rural Supplies – Lift and distribute bulk feed, fertilisers, and rural essentials effortlessly.
✔ Landscaping – Ideal for transporting soil, mulch, and other landscaping materials with ease.
✔ Self-Storage – Move and manage storage containers, pallets, and goods with precision.
✔ Hardware Store Deliveries – Handle a wide range of materials including timber, plasterboard, and steel efficiently.
✔ Waste Management & Recycling – Built tough for unpredictable and harsh environments.
✔ Bee Keeping – Transport beekeeping equipment, hives, and honey supplies with care.
✔ Events Industry – Move staging, marquees, and heavy event equipment quickly and safely.
✔ General Freight – Designed to handle a variety of goods for seamless freight transportation.
✔ Taxi Trucks – Perfect for fast, reliable transport of pallets and bulk goods.
Built for Safety, Engineered for Efficiency
Operator safety and comfort are at the core of the Loadmac 825 Super Reach. With a 2,500kg lifting capacity and an ergonomically designed operator station, it provides maximum visibility and control.
Ground-level access for mounting and dismounting ensures reduced physical strain, keeping operators safe and productive.
Industry-Leading One-Side Offloading
The Integrated Second Reach (iSR) system allows for true one-side unloading, even inside a curtainsider—saving time and reducing manual handling. This innovative feature maximises efficiency and streamlines transport, logistics, and material handling operations.
Ultimate Stability & Control
Whether operating on rugged terrain or in confined spaces, the Loadmac 825 Super Reach is designed for unmatched stability. The 4-way model features multi-directional steering, allowing it to move sideways—perfect for handling long loads like scaffolding, timber, and steel beams.
Built to Last with Patented Rust-Proofing
Constructed for durability, the Loadmac 825 Super Reach features a patented autophoretic rust-proofing process, ensuring exceptional longevity even in harsh conditions. Backed by a two-year warranty, it's designed for reliable, long-term performance.
Built for Safety, Engineered for Efficiency
Operator safety and comfort are at the core of the Loadmac 825 Super Reach. With a 2,500kg lifting capacity and an ergonomically designed operator station, it provides maximum visibility and control.
Ground-level access for mounting and dismounting ensures reduced physical strain, keeping operators safe and productive.
Industry-Leading One-Side Offloading
The Integrated Second Reach (iSR) system allows for true one-side unloading, even inside a curtainsider—saving time and reducing manual handling. This innovative feature maximises efficiency and streamlines transport, logistics, and material handling operations.
Ultimate Stability & Control
Whether operating on rugged terrain or in confined spaces, the Loadmac 825 Super Reach is designed for unmatched stability. The 4-way model features multi-directional steering, allowing it to move sideways—perfect for handling long loads like scaffolding, timber, and steel beams.
Built to Last with Patented Rust-Proofing
Constructed for durability, the Loadmac 825 Super Reach features a patented autophoretic rust-proofing process, ensuring exceptional longevity even in harsh conditions. Backed by a two-year warranty, it's designed for reliable, long-term performance.
Need Something More Compact? Meet the Loadmac 225
If your operation requires a lighter, more agile solution, the Loadmac 225 delivers outstanding performance in a smaller, more manoeuvrable package. Perfect for tight spaces, urban deliveries, and lighter loads, it still packs the power and reliability you expect from Loadmac—without the footprint of a larger model.
Ideal for:
✔ Urban & restricted access sites
✔ Lightweight materials & general freight
✔ Fast, efficient offloading in tight spaces
